Anschutz 9015 Air Rifle One Basic
Model 9015 ONE BASIC
The new ANSCHUTZ 9015 ONE BASIC is a target air rifle based on our successful and unique 9015 ONE model. The outstanding precision and various adjustment possibilities of the fore-end combined with the unrivaled target two-stage trigger 5065 4K are complimented with the newly developed rear section of the 9015 ONE BASIC stock. The solid and robust stock is equipped with the well-known and common ANSCHUTZ butt plate and cheek piece adjustments which have been proven over many years.
The modular construction of the ONE-stock
The stock, including grip, can be separated from the fore-end in just a few seconds by simply releasing one screw. It can then be reassembled precisely without any play to form a 100% rigid connection. This offers you the opportunity to change the ONE Basic rear section for the rear section of the 9015 ONE, allowing for even more adjustment possibilities and stock positions.
Technical data sheet
All technical data
Total length (cm):110.5 - 11
Total weight (kg):4.2
Barreled Action:
Caliber:4.5 mm
Rifling (mm):420
Length of twist (mm):480
Number of grooves:12
Barrel length (mm):420
Length of the barrel unit (mm):592
Length of aiming (mm):620 - 897
Muzzle diameter (mm):22
Safety:yes
Version:right/left
Length of barreled action (mm):734 - 844
Weight (g):2400
Trigger:
Type:Two stage trigger 5065 4K
Version:right
Tilting range (mm):11
Adjustment of the trigger shoe (mm):22
Trigger blade:007434
Color of the trigger shoe:Silver
Trigger weight, adjusted (g):100
Adjustment of the trigger weight (mm):30-170
Sight set:
Type:Rear sight and front sight
Stock:
Aluminuim grooved rail on the lower side:yes
Length of stock (mm):767 - 807
Material:Aluminum / Stainless steel / Carbon
Stock color:black / silver / red
Length of pull (mm):310 - 365
Grip:yes
Version:right/left
Grip size:M
Grip material:Walnut
Grip color:naturally oiled
Butt Plate:
Material:
Adjustable (mm):60 mm
Weight (g):225 g
Butt Plate Carrier:
Material:Aluminum
Column distance (mm):30
Column diameter (mm):12
Length (mm):77
Weight (g):90
Fore-end:
Material:Walnut
Adjustable in height (mm):95
Tilting (degree):360
Weight (g):350
Adjustment Forward - Backward (mm):160
Grip:
Material:Walnut
Color:oiled
Size:M
Length (mm):75
Width (mm):50
Height (mm):95
Weight (g):105
Version:right
